Garmin Force Trolling Motor

Item No. 75375921766

Select Delivery Method:

Free Shipping

Est. Delivery Fri. 3/24 - Mon. 3/27

Fish with Force
The Garmin Force Trolling Motor is the most powerful and most efficient trolling motor on the market. Press play to learn about the advanced features of this Garmin trolling motor.

Garmin Force Trolling Motor


The Garmin Force Trolling Motor is the most powerful and efficient 50-inch trolling motor available. This Garmin trolling motor quickly deploys and easily retracts and stows thanks to dual gas springs. Integrated CHIRP, ClearVü, and SideVü scanning sonars provide a clear picture of the surrounding waters, while built-in GPS, auto-pilot functionality, and a heading sensor allow you to easily mark and move between your favorite spots and waypoints. The Garmin Force 50-inch motor includes a foot pedal and wireless remote for easy, quick control and operates with electric steering. With a high-efficiency motor, the Garmin Force Trolling Motor delivers powerful thrust in a quiet motor with simple point-and-go steering. It operates at either 36 V or 24 V. When running at 24 V, it delivers comparable thrust to the competitors’ 36-V motors.

  • AutoPilot
  • Anchor Lock
  • Heading Hold
  • Cruise Control
  • Route Following
  • ClearVü: 200 ft.
  • SideVü: 455 kHz
  • ClearVü: 800 kHz
  • Transmit Power: 350 W
  • ClearVu: Ultra-high-definition 800 kHz
  • Maximum Depth CHIRP Sonar: 800 ft.
  • Number of Pins: 12 (orange connector)
  • Gesture Features (manual+, heading hold+, jog+)
  • 455 kHz SideVü: 500 ft. to each side; 1000 ft. total
  • SideVu: Ultra-high-definition 1200 kHz and 455 kHz
  • Frequencies supported CHIRP sonar: High-wide CHIRP (150-240 kHz), ClearVu: Ultra-high definition 800 kHz, SideVu: Ultra-high definition 1200 kHz and 455 kHz
  • Partial Frequencies Supported CHIRP Sonar: High-wide CHIRP (150-240 kHz), ClearVü: 800 kHz, SideVü: 455 kHz
  • Maximum view: CHIRP sonar: 800', ClearVü: 200', Ultra-high definition SideVü: 125' to each side; 250 total at a max depth of 30', 455 kHz SideVü: 500' to each side; 1000' total
Foot Pedal:
  • Wireless Communication
  • Waterproof Rating: IPX7
  • AA Battery Life: 1 full season
  • Adjustable Pedal Resistance
  • Dimensions: 12" L x 9" W x 4.5" H
  • Power Installation: 12V wired or battery-powered (2 AA)
  • Waterproof Rating: IPX7
  • Autopilot Feature Control
  • Display Resolution: 240 x 240 pixels
  • Display Size: 1.2" (30.4 mm) diameter
  • Chartplotter User-Programmable Keys
  • Battery Life (Typical Use with Low Backlight): 43.2 weeks
  • Display Type Color, Sunlight-Visible, Transflective Memory-in-Pixel (MIP)
In the Box:
  • Trolling Motor
  • Built-in GT54UHD-TM transducer
  • Foot Pedal
  • Remote
  • High Efficiency Propeller
  • Stabilizer
  • Assembly and Mounting Hardware
  • Documentation
  • Electric steering for easier operation
  • Built-in GPS, heading sensor, and auto-pilot
  • Dual gas springs offer easy stowing and deployment
  • Integrated CHIRP, ClearVü, and SideVü scanning sonars
  • Included foot pedal and wireless remote for quick control
  • High-efficiency motor delivers reliable thrust with quiet operation
  • Durable and easy to use
  • Powerful, efficient, and quiet
  • Wireless foot pedal provides instant control and responsiveness
  • Wireless Chartplotter integration and built-in autopilot provide guidance
  • Convenient Remote with point and go steering and user-programmable keys
  • Integrated transducer with CHIRP traditional and HD ClearVü and SideVü sonars
  • Shaft Length: 50 in.
  • Built-in heading sensor
  • Mounting location bow
  • Lift-assist dual gas springs
  • Mount style: scissor-style mount
  • Variable speed control (20 steps)
  • Built-in GPS (high-sensitivity GPS)
  • Warranty: 3-year, limited lifetime on shaft
  • Water Rating (components above water): IPX7
  • For use in freshwater; warranty also covers saltwater/brackish water use
  • Max thrust: 100 lbs Per ISO 13342 using high-efficiency propeller at 36V; 80lbs per 13342 using high-efficiency propeller at 24 Vdc
  • Voltage: 24 V or 36 V
  • Shaft length: 57 inch
  • Manufacturer's Warranty: 3-year, limited lifetime on shaft
  • Max Thrust: 100 lbs. per ISO 13342 (high-efficiency propeller at 36V); 80 lbs. per ISO 13342 (high-efficiency propeller at 24Vdc)
  • Electric steering
  • Battery indicator
