Humminbird Helix 7 CHIRP Mega DI GPS G4N CHO

Item No. 08232405622
itemprop="price">699.99 $699.99

Select Delivery Method:

Free Shipping

Est. Delivery Tue. 6/6 - Thur. 6/8

Frequently Bought With

Humminbird Helix 7 CHIRP Mega DI GPS G4N CHO


Control Head Only Model: This model does not include a transducer.

  • Compatible with optional premium charts from Humminbird's LakeMaster® and CoastMaster™ products as well as select Navionics® charts
  • NMEA 2000 networking built-in: Connect an accessory NMEA 2000 network to your control head for boat performance information, weather and water conditions, and more
  • Bluetooth connectivity allows wireless communication to compatible Talon and Raptor shallow water anchors and wireless software updates from the Humminbird FishSmart App
  • Dual Spectrum CHIRP sonar provides highly-detailed fish arches and a clear view of structure and the bottom, plus two modes: Wide Mode for maximum coverage and Narrow Mode for focusing on details
  • Internal GPS and Humminbird Basemap provides a clear view of underwater terrain, contours, depth markers, and other points of interest on more than 10,000 lakes plus continental US coastal coverage
  • AutoChart Live creates real-time maps of your fishing spots with access to patented Humminbird® LakeMaster® features, map depth contours, bottom hardness, and vegetation as you drive your boat
  • Ethernet networking allows you to connect multiple fish finders or add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar
  • MEGA Down Imaging with coverage down to 125 feet below your boat. and up to 3X more detail than standard Down Imaging
  • Integrates with other Humminbird and Minn Kota products as part of the One-Boat Network
  • Control Head Only Model: This model does not include a transducer.
  • Manufacturer's 1-Year Limited Warranty
  • Keypad control with a user-friendly menu system
  • Includes control head, power cable, gimbal mounting bracket, and mounting hardware
  • Depth Sonar: 1,200 ft (standard transducer), 3,500 ft (optional 50 kHz)
  • CHIRP Imaging-Frequencies Supported: 455 kHz (440-500 kHz), MEGA DI (1075-1150 kHz)
  • CHIRP Frequencies Supported: 83/200 (75-155/130-250 kHz), Full Mode (150-220 kHz), Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz)
  • Compatible With: AIS, AutoPilot, MEGA Live, Minn Kota Built-In MEGA DI, Minn Kota i-Pilot Link, Minn Kota Talon/Raptor, Minn Kota US2 Sonar, NMEA 2000, One-Boat Network, Radar
  • Temperature: Built-In
  • HDMI Compatible: No
  • View Preset Keys: Yes
  • Temperature Alarm: Yes
  • Temperature Graph: Yes
  • Upgradable Software: Yes
  • Platinum Compatibility: Yes
  • X-Press Menu System: Yes
  • Sonar Recording: Included
  • Sonar Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz
  • Sonar Standard: Dual Spectrum CHIRP, MEGA Down Imaging
  • Depth Down Imaging: 400 ft (455 kHz), 75 ft (MEGA)
  • Power Draw: 800 mA
  • Mount Standard: Gimbal
  • Interface: Keypad Control
  • Power Input: 10.8-20 VDC
  • Display Size (Diagonal): 7 in.
  • Power Output RMS: 500 Watts
  • Memory Card Slot: Dual Micro SD
  • Display Pixel Matrix: 1024H x 600V
  • Power Output Peak-to-Peak: 4000 Watts
  • Sonar Optional: 53 kHz, 50/Low Airmar CHIRP
  • Mount Standard Size: 10.54" W x 5.8" H x 3.68" D
  • Sonar Coverage: 20°, 42°, 60° & (2) 86° @ -10dB
  • Screen Snap Shot: Included
  • GPS Chartplotting: Included
  • GPS Trackplotting: Included
  • Custom View Selections: No
  • Custom Digital Readout: Yes
  • MEGA Live Compatibility: Yes
  • LakeMaster Compatibility: Yes
  • Coast Master Compatibility: Yes
  • Display Colors Grayscale: 16-Bit
  • Navionics Platinum + Compatibility: Yes
  • Heading Sensor GPS Compatibility: Yes
  • Navionics Gold/HotMaps Compatibility: Yes
