Ravin R26 Crossbow

Item No. 81594202026

Select Delivery Method:

Free Shipping

Est. Delivery Fri. 3/24 - Mon. 3/27

The Most Compact & Lightweight Crossbow
Built for accuracy and superior performance, the Ravin R26 is the most compact and lightweight crossbow on the market. Press play to witness the unbelievable power and speed of this crossbow to take your hunting adventures to new levels.

Ravin R26 Crossbow


The Ravin R26 Crossbow is compact and lightweight but still delivers devastating speeds and exceptional accuracy. This Ravin crossbow features a FrictionlessTM Flight System that keeps the string and arrow above the rail to improve downrange accuracy and increase string life. The Trac-TriggerTM Firing System ensures straight nock travel to further improve precision, while the Versa-DrawTM Cocking System easily cocks with only 12-pounds of force. For added safety, the R26 has an Anti-Dry Fire system that engages an auto safety when the crossbow is cocked without an arrow. Capable of producing speeds up to 400 FPS, the Ravin R26 Crossbow offers unmatched precision and power in an extremely lightweight and compact crossbow.


  • (3) 400 gr .003 arrows
  • Removable draw handle
  • 100 yd. illuminated scope
  • Quiver & mounting bracket
  • (3) 100 gr. practice field points
  • Versa-Draw™ Cocking System requires only 12 lbs. of force
  • Frictionless™ Flight System improves accuracy and string life
  • Trac-Trigger™ Firing System ensures straight-line nock travel
  • Anti-Dry Fire auto safety locks trigger when no arrow is inserted
  • HeliCoil® technology for speed, power, and accuracy
  • Delivers speeds up to 400 FPS
  • Built-in cocking mechanism
  • Integral sling mounts
  • Model #: R026
  • Length: 26 in.
  • Weight: 6.5 lbs.
  • Draw Weight: 12 lbs.
  • Power Stroke: 9.5 in.
  • Kinetic Energy: 142 FP
  • Velocity: 400 FPS (400 gr.)
  • Width Axle-to-Axle: 9.25 in. (uncocked), 5.75 in. (cocked)
